RADWAG XA 82/220.5Y.A XA 5Y.A Analytical Balance, 82/220g Capacity, 0.01/0.1mg Readability, Internal Calibration, OIML Class I

RADWAG XA 82/220.5Y.A Analytical Balance — Dual-Range Precision with Automated Operation

Laboratories requiring flexible weighing across varying sample sizes will appreciate the RADWAG XA 82/220.5Y.A Analytical Balance. This dual-range instrument delivers 0.01 mg readability up to 82 g and 0.1 mg readability up to 220 g, enabling fine and coarse measurements on a single platform. An integrated antistatic ionizer and automatic draftshield doors streamline every weighing session.

Key Features

• Dual-Range Flexibility: Operates at 82 g / 220 g capacity with 0.01 mg / 0.1 mg readability, adapting automatically to accommodate both micro-samples and larger loads without instrument changes.
• Built-In Antistatic Ionizer: Neutralizes electrostatic charge on samples and containers before they reach the pan, eliminating a common source of measurement drift in analytical work.
• Automatic Internal Calibration: Motor-driven calibration triggers without user intervention, keeping sensitivity within specification throughout long shifts and changing environmental conditions.
• 10-Inch Touchscreen with Widgets: A responsive display presents live environmental data, weighing graphs, and status indicators on customizable screens for rapid interpretation of results.
• Fully Automatic Leveling (ReflexLEVEL): The balance continuously monitors and corrects its level, removing a manual step that can introduce error if overlooked between tasks.
• Comprehensive Connectivity: USB-A, USB-C, HDMI, Ethernet, Wi-Fi, and Hotspot interfaces allow direct data transfer to LIMS, printers, or remote displays without additional adapters.

Detailed Overview

The XA 82/220.5Y.A belongs to RADWAG's 5Y.A series, pairing a high-resolution electromagnetic force restoration sensor with automated chamber doors and an integrated ionizer. Repeatability at 5 % of maximum capacity reaches 0.005 mg, while linearity stays within ±0.06 mg on the fine range — specifications that support quantitative pharmaceutical assays and reference standard preparations. The automatic weighing chamber opens and closes at the touch of a button or via infrared proximity sensors, reducing vibration-induced disturbance and enabling touch-free workflows. With 21 CFR Part 11 compliance built into the firmware, electronic signatures, audit trails, and user verification through passwords, RFID, or biometric methods are available for regulated environments.

Applications

• Pharmaceutical quality control and raw-material release testing
• Reference standard and calibration weight verification
• Chemical research and reagent preparation
• Environmental sample analysis in accredited laboratories
• Academic research requiring traceable, high-resolution measurements

Why Choose the RADWAG XA 82/220.5Y.A?

For teams that handle diverse sample masses daily, this dual-range analytical balance removes the need for two separate instruments. OIML Class I certification, 21 CFR Part 11 support, and automatic calibration make it well suited to GMP, GLP, and ISO-accredited facilities. Add the XA 82/220.5Y.A to your cart and consolidate your analytical weighing workflow into one reliable platform.
