RADWAG MA 50.5Y.WH MA 5Y.WH Moisture Analyzer, 50g Capacity, 1mg Readability
RADWAG MA 50.5Y.WH Moisture Analyzer — Advanced 50 g Analysis with Four Drying Modes
Moisture analysis across diverse materials demands adaptable drying profiles, and the RADWAG MA 50.5Y.WH Moisture Analyzer delivers four distinct modes — Standard, Mild, Fast, and Step — through a 10-inch touchscreen interface. With 50 g capacity, 1 mg readability, and an automatic drying chamber, this instrument brings flexibility and precision to every moisture determination task.
Key Features
- Four Drying Modes: Standard, Mild, Fast, and Step profiles let operators match the heating programme to each material — from heat-sensitive leather to fast-drying granulates — maximising accuracy and throughput.
- Automatic Drying Chamber: Motorised opening and closing ensure consistent conditions for every test, improve repeatability, and reduce the physical wear of manual handling.
- 10-Inch Touchscreen Display: Real-time drying curves, sample data, and instrument status are presented on a large, responsive screen that simplifies method setup and results review.
- Halogen Heater to 250 °C: Fast thermal response and even heat distribution enable shorter test cycles compared to infrared or oven-based alternatives.
- Semi-Automatic LevelSENSING: An intelligent levelling system detects tilt and provides corrective guidance, preserving weighing accuracy that underpins moisture calculations.
Detailed Overview
The MA 50.5Y.WH is part of RADWAG's 5Y moisture analyser platform, designed around the principle that different materials require different drying strategies. Mild mode applies gentle heat ramps for thermally fragile samples, while Fast mode reaches target temperature immediately for routine production checks. Step mode allows multi-temperature profiles for complex matrices. Moisture content repeatability of ±0.05 % at 2 g and ±0.01 % at 10 g meets the requirements of most standard test methods. The 90 mm pan accepts disposable inserts for rapid changeovers, and external calibration maintains the underlying weighing accuracy. Connectivity through USB, Ethernet, Wi-Fi, and hotspot allows seamless data transfer to quality-management systems and LIMS.
Applications
- Food and snack production moisture compliance checks
- Pharmaceutical powder and granulate moisture monitoring
- Textile and leather moisture assessment during processing
- Adhesive and coating formulation moisture control
Why Choose the RADWAG MA 50.5Y.WH?
The MA 50.5Y.WH Moisture Analyzer gives QC teams and production labs the drying flexibility to handle a wide range of materials without method compromise. Its automatic chamber, intuitive touchscreen, and smart levelling remove common sources of operator variability. Shop at Weighcore and bring adaptive moisture analysis to your laboratory.
| Maximum capacity | 50 g |
|---|---|
| Readability | 1 mg |
| Moisture content readability | 0.001% |
| Heating module | halogen |
| Heating module power | 450 W |
| Drying temperature range | max 250 °C |
| Drying temperature control | One- or two-point, depending on the drying profile (equipment: GT105k-12/Z Control Thermometer) |
| Drying temperature adjustment | Three-point adjustment at defined temperatures, programmable values (equipment: GT105k-12/Z Control Thermometer) |
| Display | 10″ touchscreen |
| Display mode | %MC, %DC, %ATRO MC, %ATRO DC, g, g/kg MC, g/kg DC, -%MC |
| Communication interface | USB-A ×2, USB-C, HDMI, Ethernet, Wi-Fi®, Hotspot |
| Weighing pan dimensions | ø90, h= 8 mm |
| Net weight | 5.3 kg |
| Tare range | -50 g |
| Calibration | external |
| Maximum sample weight | 50 g |
| Moisture content repeatability | +/-0.05% (sample ~ 2g), +/-0.01% (sample ~ 10g) |
| Leveling system | semi-automatic - LevelSENSING |
| Weighing chamber | automatic |
| Maximum sample height | 20 mm |
| Protection class | IP 43 |
| Drying method | 4 drying profiles (standard, fast, step, mild) |
| Finish mode | 4 modes (automatic, manual, time-defined, user-defined) |
| Additional functions | sample traceability |
| Power supply | 100V – 120V AC 50/60Hz or 200V-240V AC 50/60Hz |
| Power consumption | 6 W |
| Operating temperature | +10 — +40 °C |
| Mass indication control | External mass standard 50 g, 100 g, 200 g (depending on the type of moisture analyzer) |
| Internal adjustment | For .IC models only, GLP report |
| External adjustment | For all models, GLP report |
| Moisture content indication control | Certified MV Test Set |
| Internal / External adjustment | Depending on the type of moisture analyzer, GLP report |
