RADWAG MA 50/1.5Y.IC MA 5Y.IC Moisture Analyzer, 50g Capacity, 0.1mg Readability, Internal Calibration
RADWAG MA 50/1.5Y.IC Moisture Analyzer — Internal Calibration with Four Drying Modes
Maintain traceable moisture measurement accuracy with the RADWAG MA 50/1.5Y.IC Moisture Analyzer. Equipped with internal automatic calibration, a 50 g capacity, and 0.1 mg readability, this 5Y-series analyzer gives quality teams confidence that every result reflects true sample moisture content, even over extended periods between external verifications.
Key Features
- Internal Automatic Calibration: Adjusts the weighing system on-board, eliminating the need for external calibration weights and reducing instrument downtime during busy production schedules.
- Four Targeted Drying Modes: Standard, mild, fast, and step profiles let operators match the heating program to each material's thermal sensitivity, protecting delicate samples while accelerating robust ones.
- 0.1 mg Readability: Captures small mass changes during drying, yielding moisture content readability of 0.0001 percent for precise determination of low-moisture materials.
- 10-Inch Touchscreen Interface: Large display area presents drying curves, numerical results, and stored methods clearly, enabling quick program changes and data review between runs.
- Semi-Automatic LevelSENSING: Monitors and alerts operators to leveling deviations, maintaining optimal measurement conditions even on surfaces prone to vibration or unevenness.
- Infrared Emitter Heating: Distributes heat uniformly up to 160 degrees Celsius, accommodating powders, granules, pastes, and a wide variety of industrial and laboratory samples.
Detailed Overview
The MA 50/1.5Y.IC belongs to the RADWAG MA 5Y.IC series, designed for facilities that need self-calibrating moisture analyzers capable of meeting GLP and GMP documentation standards. The instrument achieves moisture content repeatability of plus or minus 0.05 percent for 2 g samples and plus or minus 0.01 percent for 10 g samples, confirming reproducibility across typical test portions. A comprehensive set of connectivity options — including RS 232, USB-A, USB-B, Ethernet, and Wi-Fi — allows seamless transfer of results to LIMS, ERP, and quality management platforms. The THBR 2.0 ambient monitoring system records environmental conditions alongside each drying test, providing context for variance analysis and regulatory documentation.
Applications
- Pharmaceutical moisture testing requiring self-calibrating instruments
- Food production quality assurance for baked goods, grains, and snacks
- Plastics and polymer incoming material verification
- Chemical manufacturing process control and batch release testing
Why Choose the RADWAG MA 50/1.5Y.IC?
Internal calibration means this moisture analyzer is always ready for accurate measurements without scheduling external calibration sessions. Combined with versatile drying modes and a generous touchscreen, it streamlines moisture analysis workflows in regulated and production settings. Order the MA 50/1.5Y.IC today to keep your quality program on track.
| Maximum Capacity | 50 g |
|---|---|
| Readability | 0.1 mg |
| Maximum Sample Weight | 50 g |
| Heater Type | IR emitter |
| Temperature Range | max 160 °C |
| Moisture Content Readability | 0.0001% |
| Moisture Content Repeatability | +/-0.05% (sample ~ 2g), +/-0.01% (sample ~ 10g) |
| Calibration | internal (automatic) |
| Leveling System | semi-automatic - LevelSENSING |
| Pan Size | ø90, h= 8 mm |
| Maximum Sample Height | 20 mm |
| Display | 10″ touchscreen |
| Connectivity | USB-A ×2, USB-C, HDMI, Ethernet, Wi-Fi®, Hotspot |
| Operating Temperature | +10 — +40 °C |
| Protection Class | IP 43 |
| Power Supply | 100V – 120V AC 50/60Hz or 200V-240V AC 50/60Hz |
| Power Consumption | 6 W |
| Tare Range | -50 g |
| Net Weight | 5.3 kg |
| Weighing chamber | automatic |
| Display mode | %MC, %DC, %ATRO MC, %ATRO DC, g, g/kg MC, g/kg DC, -%MC |
| Drying method | 4 drying profiles (standard, fast, step, mild) |
| Finish mode | 4 modes (automatic, manual, time-defined, user-defined) |
| Additional functions | sample traceability |
| Heating module power | 450 W |
| Mass indication control | External mass standard 50 g, 100 g, 200 g (depending on the type of moisture analyzer) |
| Internal adjustment | For .IC models only, GLP report |
| External adjustment | For all models, GLP report |
| Drying temperature control | One- or two-point, depending on the drying profile (equipment: GT105k-12/Z Control Thermometer) |
| Moisture content indication control | Certified MV Test Set |
| Internal / External adjustment | Depending on the type of moisture analyzer, GLP report |
| Drying temperature adjustment | Three-point adjustment at defined temperatures, programmable values (equipment: GT105k-12/Z Control Thermometer) |
