RADWAG MA X7.IC.A.WH MA 200/1.X7.IC.A.WH Moisture Analyzer, 200g Capacity, 0.1mg Readability, Halogen, 250°C Max
RADWAG MA 200/1.X7.IC.A.WH Moisture Analyzer — 200 g Halogen Analyzer with 0.1 mg Precision
Large-sample moisture analysis at analytical-grade resolution is now within reach. The RADWAG MA 200/1.X7.IC.A.WH Moisture Analyzer combines a 200 g capacity with 0.1 mg readability and a halogen drying lamp capable of reaching 250 °C, providing the sensitivity and power needed for thorough moisture characterisation of diverse materials.
Key Features
- 200 g Capacity with 0.1 mg Readability: Weigh larger samples while detecting even trace levels of moisture, with a moisture content readability of 0.0001% that rivals dedicated laboratory balances.
- Halogen Lamp Heating to 250 °C: High-intensity infrared energy penetrates samples quickly and uniformly, significantly reducing drying times for thermally resistant or dense materials.
- Automated Drying Chamber with IR Sensors: The motorised lid opens and closes through buttons or proximity sensors, preserving hygienic conditions and ensuring repeatable sample placement.
- 7-Inch Colour Touchscreen: Graphical interface with touch-free navigation via two programmable IR sensors provides clear drying curve displays, method management, and result review.
- Comprehensive Drying Flexibility: Four drying profiles and four finish modes cover the full spectrum of sample types and testing standards, from production-floor checks to reference laboratory methods.
Detailed Overview
The RADWAG MA 200/1.X7.IC.A.WH Moisture Analyzer brings together the X7 platform's intuitive interface with the WH series halogen technology and the A series automated chamber. Sample traceability functions document every analysis from start to finish, supporting quality system requirements and regulatory audits. The ø90 mm pan accommodates samples up to 20 mm high, and external calibration with GLP report generation verifies both mass and temperature accuracy. RS232, USB-A, USB-B, Ethernet, and Wi-Fi interfaces handle data export to LIMS platforms, label printers, and networked quality management systems. With a heating module power of 450 W, the halogen lamp reaches target temperatures rapidly, maximising laboratory productivity.
Applications
- Large-batch moisture verification in food processing plants
- Pharmaceutical production moisture monitoring at scale
- Chemical and petrochemical sample analysis
- Building material and mineral moisture content determination
Why Choose the RADWAG MA 200/1.X7.IC.A.WH?
When your application demands both high sample capacity and analytical-level sensitivity, this moisture analyzer delivers. Its automated chamber, powerful halogen heating, and detailed traceability features support high-throughput environments where accuracy and documentation are equally important. Order today to handle your most demanding moisture analysis tasks with confidence.
| Maximum Capacity | 200 g |
|---|---|
| Readability | 0.1 mg |
| Moisture content readability | 0.0001% |
| Maximum sample weight | 200 g |
| Heating module | halogen |
| Heating module power | 450 W |
| Drying temperature range | Max 250 °C |
| Drying method | 4 drying profiles (standard, fast, step, mild) |
| Moisture content repeatability | +/-0.05% (sample ~ 2g), +/-0.01% (sample ~ 10g) |
| Display | 7″ graphic colour touchscreen |
| Display mode | %MC, %DC, %ATRO MC, %ATRO DC, g, g/kg MC, g/kg DC, -%MC |
| Finish mode | 4 modes (automatic, manual, time-defined, user-defined) |
| Weighing pan dimensions | ø90, h= 8 mm |
| Maximum sample height | 20 mm |
| Weighing chamber | automatic |
| Communication interface | RS232¹, USB-A, USB-B, Ethernet, Wi-Fi® |
| Calibration | external |
| External adjustment | For all models, GLP report |
| Internal / External adjustment | Depending on the type of moisture analyzer, GLP report |
| Internal adjustment | For .IC models only, GLP report |
| Drying temperature control | One- or two-point, depending on the drying profile (equipment: GT105k-12/Z Control Thermometer) |
| Drying temperature adjustment | Three-point adjustment at defined temperatures, programmable values (equipment: GT105k-12/Z Control Thermometer) |
| Mass indication control | External mass standard 50 g, 100 g, 200 g (depending on the type of moisture analyzer) |
| Moisture content indication control | Certified MV Test Set |
| Additional functions | sample traceability |
| Leveling system | manual |
| Protection class | IP 43 |
| Operating temperature | +10 — +40 °C |
| Power supply | 100V – 120V AC 50/60Hz or 200V-240V AC 50/60Hz |
| Power consumption | 6 W |
| Net weight | 5.2 kg |
| Tare range | -200 g |
