RADWAG MA 200/1.5Y.NS MA 5Y.NS Moisture Analyzer, 200g Capacity, 0.1mg Readability
RADWAG MA 200/1.5Y.NS Moisture Analyzer — Sub-Milligram Readability for Demanding Moisture Work
When standard milligram resolution is not enough, the RADWAG MA 200/1.5Y.NS Moisture Analyzer raises the bar with 0.1 mg readability across a 200 g capacity range. Its metal heater module, four drying profiles, and 10-inch touchscreen with automatic chamber make this instrument suitable for laboratories that require both high capacity and exceptional measurement granularity in their moisture determinations.
Key Features
- 200 g Capacity with 0.1 mg Readability: Sub-milligram weighing resolution on a high-capacity platform provides the sensitivity to detect small moisture differences in large or dense samples.
- 0.0001 % Moisture Content Readability: Extremely fine moisture resolution supports applications where even minor variations in moisture content carry significant implications for product quality.
- Metal Heater to 160 °C: Reliable heating technology with low maintenance requirements ensures consistent energy transfer across thousands of drying cycles.
- 10-Inch Touchscreen Interface: Configure drying parameters, review historical results, and manage user profiles through a large, responsive display.
- Automatic Weighing Chamber and LevelSENSING: Motorized chamber operation and semi-automatic levelling reduce manual steps, improving both speed and measurement consistency.
Detailed Overview
The MA 200/1.5Y.NS achieves moisture content repeatability of ±0.05 % for 2 g samples and ±0.01 % for 10 g samples. Its generous 200 g capacity suits laboratories that test larger sample quantities for better statistical representation of bulk materials. External calibration with certified weights maintains weighing traceability, and the broad connectivity suite — USB-A, USB-C, HDMI, Ethernet, Wi-Fi, and Hotspot — ensures data flows seamlessly to quality management platforms. Four finish modes (automatic, manual, time-defined, user-defined) give operators full control over drying endpoints, while the multiple display modes accommodate various reporting conventions.
Applications
- Pharmaceutical active ingredient and excipient moisture testing
- High-precision moisture analysis in chemical R&D laboratories
- Incoming material inspection for moisture-sensitive production processes
- Environmental and agricultural soil moisture studies
Why Choose this moisture analyzer?
The MA 200/1.5Y.NS delivers a rare combination of high capacity and sub-milligram readability, meeting the needs of laboratories where both sample size and measurement precision are non-negotiable. Its touchscreen workflow, automated features, and extensive connectivity streamline operations in regulated and research environments alike. Order today and elevate your moisture analysis precision.
| Maximum Capacity | 200 g |
|---|---|
| Readability | 0.1 mg |
| Moisture content readability | 0.0001% |
| Heating module | metal heater |
| Heating module power | 450 W |
| Tare range | -200 g |
| Maximum sample weight | 200 g |
| Moisture content repeatability | +/-0.05% (sample ~ 2g), +/-0.01% (sample ~ 10g) |
| Drying temperature range | max 160 °C |
| Drying method | 4 drying profiles (standard, fast, step, mild) |
| Finish mode | 4 modes (automatic, manual, time-defined, user-defined) |
| Display | 10″ touchscreen |
| Display mode | %MC, %DC, %ATRO MC, %ATRO DC, g, g/kg MC, g/kg DC, -%MC |
| Weighing pan dimensions | ø90, h= 8 mm |
| Weighing chamber | automatic |
| Maximum sample height | 20 mm |
| Leveling system | semi-automatic - LevelSENSING |
| Communication interface | USB-A ×2, USB-C, HDMI, Ethernet, Wi-Fi®, Hotspot |
| Protection class | IP 43 |
| Operating temperature | +10 — +40 °C |
| Power supply | 100V – 120V AC 50/60Hz or 200V-240V AC 50/60Hz |
| Power consumption | 6 W |
| Mass indication control | External mass standard 50 g, 100 g, 200 g (depending on the type of moisture analyzer) |
| Internal adjustment | For .IC models only, GLP report |
| External adjustment | For all models, GLP report |
| Internal / External adjustment | Depending on the type of moisture analyzer, GLP report |
| Drying temperature control | One- or two-point, depending on the drying profile (equipment: GT105k-12/Z Control Thermometer) |
| Drying temperature adjustment | Three-point adjustment at defined temperatures, programmable values (equipment: GT105k-12/Z Control Thermometer) |
| Moisture content indication control | Certified MV Test Set |
| Additional functions | sample traceability |
| Net weight | 5.3 kg |
| Calibration | external |
