KERN & SOHN NXC 1.5T-4M NXC Truck Scale, 1500 kg Capacity, 0.5 kg Readability, IP68 Rated, RS-232 / USB

KERN & SOHN NXC 1.5T-4M Truck Scale — 1500 kg Capacity, OIML Class III, IP68 Indicator

When legal-for-trade precision meets IP68 ingress protection, the KERN & SOHN NXC 1.5T-4M Truck Scale is the result—1500 kg capacity, 0.5 kg readability, and OIML Class III certification in a rugged floor scale built for the most demanding industrial environments. The KERN & SOHN NXC 1.5T-4M Truck Scale serves heavy industry, food production, and freight logistics wherever both legal-for-trade accuracy and superior washdown resistance are required.

Key Features

• IP68 indicator / IP67 platform: The IP68-sealed display housing and IP67-protected platform and load cell enable complete washdown cleaning after every weighing cycle.
• OIML Class III / EC type approval: Certified for commercial freight, customs, and regulated trade transactions across the EU and international markets.
• KERN IoT-ready with KCP: KERN Communication Protocol accepts optional RS-232, USB, Bluetooth BLE, Ethernet, and Wi-Fi for automated data capture in factory and logistics systems.
• Checkweighing with visual tolerance signal: Programmable upper and lower limits trigger a display indicator for fast batch acceptance and compliance sorting.
• Alibi memory (factory option): Tamper-proof record of each weighing event for audit trails and legal-for-trade compliance documentation.
• EasyTouch compatible: Optional touchscreen module speeds operator navigation through application modes on busy production floors.

Detailed Overview

The KERN & SOHN NXC 1.5T-4M Truck Scale pairs a 63.0×48.0 in powder-coated steel platform with an IP68-rated stainless steel indicator, offering the highest water resistance in its class. An IP68 strain-gauge load cell delivers 1500 kg and 0.5 kg readability through a 30,000-count resolution with 3 s stabilisation. The KERN Communication Protocol (KCP) interface supports optional RS-232, USB, Bluetooth BLE (v4.0), Ethernet, and Wi-Fi for WMS and IoT integration. Application modes include piece counting, sum memory, percentage determination, hold, and checkweighing; factory options add alibi memory, analogue outputs, and GLP/ISO printouts. OIML Class III and EC type approval confirm legal-for-trade certification. Operating temperature: -10°C to 40°C (14°F to 104°F) with 10-minute warm-up.

Applications

• Legal-for-trade freight and cargo weighing at commercial loading docks
• Food production and processing lines requiring full washdown capability
• Industrial receiving and despatch in heavy manufacturing facilities
• Agricultural bulk produce weighing with official certification requirements
• Automated data capture in IoT-connected production environments

Why Choose the KERN & SOHN NXC 1.5T-4M?

The KERN & SOHN NXC 1.5T-4M Truck Scale is built for operations that need the highest ingress protection alongside legal-for-trade certification and IoT connectivity. Food processing, outdoor logistics, and heavy industry find that IP68 on the indicator plus IP67 on the platform eliminates the weakest point in any scale installation. Shop now at Weighcore.
