KERN & SOHN IXC 30K-3M IXC Platform Scale, 30 kg Capacity, 0.01 kg Readability, IP68 Rated, RS-232 / USB

KERN & SOHN IXC 30K-3M Platform Scale — 15 kg; 30 kg Capacity, 0.005 kg; 0.01 kg Readability, IP68 Display

The KERN & SOHN IXC 30K-3M Platform Scale is engineered for demanding industrial environments, offering 15 kg; 30 kg capacity and 0.005 kg; 0.01 kg readability with a 6-segment LCD display and load cell rated to IP65. The KERN & SOHN IXC 30K-3M Platform Scale serves warehouses, production floors, and shipping departments that need reliable industrial weighing backed by built-in piece counting, checkweighing, and sum memory functions.

Key Features

• IP68-rated display housing: The stainless steel indicator is sealed to IP68, withstanding continuous exposure to water jets and heavy condensation without compromising readout clarity.
• IP65 strain-gauge load cell: Silicone-coated aluminium load cell carries full IP65 protection, keeping moisture and dust from affecting measurement accuracy during cleaning or high-humidity operation.
• Dual weighing range: Two selectable ranges with different readabilities let operators switch between coarse and fine measurements on the same platform without changing equipment.
• Piece counting and percentage functions: Built-in PCS and percentage determination modes turn the IXC 30K-3M into a versatile production tool beyond basic weighing, supporting inventory and batching tasks.
• Checkweighing with tolerance limits: Programmable upper and lower limits trigger a visual signal when a load falls inside or outside the target zone, improving sorting efficiency without manual calculation.
• Sum memory function: Accumulated totals can be stored and recalled, supporting multi-load batching and totalising workflows across a shift or production run.

Detailed Overview

The KERN & SOHN IXC 30K-3M Platform Scale pairs a powder-coated steel deck with a stainless steel IP68 display housing, making it suitable for washdown areas and humid environments. A strain-gauge aluminium load cell rated IP65 handles 15 kg; 30 kg with selectable ranges with a 3.000, 3.000-count resolution. The wall-mountable 6-segment backlit LCD uses a 7-key panel for tare, zero, and mode switching. Standard functions include pre-tare, hold, sum memory, piece counting, and percentage determination; optional factory modules add RS-232, USB, Bluetooth BLE, analogue outputs, and alibi memory. Operating temperature spans -10°C to 40°C (14°F to 104°F) with 3 s stabilisation time.

Applications

• Incoming goods weighing in warehouses and distribution centres
• Piece counting and parts inventory on production floors
• Checkweighing and tolerance verification in quality control
• Shipping and receiving at logistics and freight depots
• Percentage-based batching in manufacturing and food processing

Why Choose the KERN & SOHN IXC 30K-3M?

The KERN & SOHN IXC 30K-3M Platform Scale suits industrial operations that need a compact, IP-protected weighing station without sacrificing functional depth—piece counting, checkweighing, and data output in a single unit. Its KERN IoT-ready design means the platform can grow with your data infrastructure as optional connectivity modules become available. Add to cart at Weighcore.
